 PIPE,CONNECTOR
| WL0113290A | 13290B | PIPE,CONNECTOR | |
HOSE,FUEL MAIN
| WL0113421A | 13421 | HOSE,FUEL MAIN | |
HOSE,FUEL RETURN
| WL0113431A | 13422 | HOSE,FUEL RETURN | AN (WL01-13-431B)
- 980301 |
| WL0113431A | 13422 | HOSE,FUEL RETURN | SGLR -201342
SGLW -202100
SGL3 -200179
SGL5 -200456 |
| WL0113431B | 13422 | HOSE,FUEL RETURN | 980301 - |
| WL0113431B | 13422 | HOSE,FUEL RETURN | SGLR 201342-
SGLW 202100-
SGL3 200179-
SGL5 200456- |
BRACKET,FUEL FILTER
| WL0113440A | 13440B | BRACKET,FUEL FILTER | |
WASHER,NOZZLE
| PN1113H51 | 136512 | WASHER,NOZZLE | |
GASKET
SHIELD,HEAT
| PN1113H53 | 13655 | SHIELD,HEAT | AN (PN11-13-H53B)
- 990901 |
| PN1113H53 | 13655 | SHIELD,HEAT | SGLR -301892
SGLW -301376 |
| PN1113H53B | 13655 | SHIELD,HEAT | 990901 - |
| PN1113H53B | 13655 | SHIELD,HEAT | SGLR 301892-
SGLW 301376- |
PIPE,FUEL LEAK
| WL0113G90B | 136702 | PIPE,FUEL LEAK | |
GASKET,LEAK PIPE
| PN1113G92A | 136712 | GASKET,LEAK PIPE | |
PIPE NO.1,INJECTION
| WL0113G10 | 137102 | PIPE NO.1,INJECTION | |
PIPE,FUEL INJECTION
| WL0113G20A | 137202 | PIPE,FUEL INJECTION | |
PIPE NO.3,INJECTION
| WL0113G30 | 137302 | PIPE NO.3,INJECTION | |
PIPE,FUEL INJECTION
| WL0113G40 | 137402 | PIPE,FUEL INJECTION | |
CLIP,INJECTION PIPE
| PN1113G45 | 13771 | CLIP,INJECTION PIPE | |
NUT,INJECTION PUMP
| RF0113802 | 13802 | NUT,INJECTION PUMP | |
STAY,INJECTION PUMP
| WL0213G0X | 13810A | STAY,INJECTION PUMP | |
GASKET,INJ.PUMP
| VS0113805 | 138122 | GASKET,INJ.PUMP | |
PROTECTOR
| WL0113886 | 13889A | PROTECTOR | |
WASHER,SHIELD HEAT-NOZZLE
| PN1113H54 | 13H54 | WASHER,SHIELD HEAT-NOZZLE | |
CLIP
BOLT & WASHER,FLANGE
| 907940825 | 90794 | BOLT & WASHER,FLANGE | |
NUT,FLANGE
| 999400500 | 90906 | NUT,FLANGE | |
| 999400801 | 90906 | NUT,FLANGE | |
HOSE
| 9934104750 | 934104 | HOSE | L=1.75M ĥAA?A ?O? |
HOSE
| 9934104750 | 935003 | HOSE | L=1.75M ĥAA?A ?O?
???A NO.1
- 990125 |
| 9934104750 | 935003 | HOSE | SGLR -300011
SGLW -300007
SGL3 -300004
SGL5 -300006 |
| 9934908750 | 935003 | HOSE | L=1.75M ĥAA?A ?O?
???A NO.2
- 980301 |
| 9934908750 | 935003 | HOSE | SGLR -201342
SGLW -202100
SGL3 -200179
SGL5 -200456 |
| 9935505090 | 935003 | HOSE | ???A NO.1
990125 - |
| 9935505090 | 935003 | HOSE | SGLR 300011-
SGLW 300007-
SGL3 300004-
SGL5 300006- |
| 9935508150 | 935003 | HOSE | ???A NO.2
980301 - |
| 9935508150 | 935003 | HOSE | SGLR 201342-
SGLW 202100-
SGL3 200179-
SGL5 200456- |
SCREW,TAPPING
| 997860820 | 99175 | SCREW,TAPPING | |
CLAMP,HOSE
| 992830800 | 99281 | CLAMP,HOSE | |
| 992831100 | 99281 | CLAMP,HOSE | |
| 992831200 | 99281 | CLAMP,HOSE | |
BOLT,FLANGE
| 997940825 | 99756 | BOLT,FLANGE | |
|
| |
